Show How You Would Add The Two Vectors Shown Below

Vector addition is a fundamental operation in physics, engineering, and mathematics, essential for understanding how forces, velocities, and displacements interact. Whether you're calculating the net force on an object or determining the total displacement of a moving body, adding vectors accurately is crucial. This guide will walk you through the process step-by-step, using a clear example to illustrate the concepts involved.

Introduction Vectors are quantities possessing both magnitude (size) and direction. Unlike scalars, which have only magnitude (like temperature or mass), vectors require special handling when combining them. The process of adding two vectors involves determining the combined effect of their individual magnitudes and directions. This article explains two primary methods for performing vector addition: the graphical method (using the parallelogram law) and the component method. Understanding both approaches provides a robust foundation for tackling more complex vector operations.

Steps for Vector Addition

Method 1: The Graphical Method (Parallelogram Law)

1. Draw Vector A: Start by sketching the first vector, Vector A, with its tail (starting point) at the origin (0,0). Use an appropriate scale and indicate its direction with an arrow.
2. Draw Vector B: From the head (tip) of Vector A, draw the second vector, Vector B, using the same scale and direction. Ensure the tail of Vector B starts precisely at the head of Vector A.
3. Draw the Resultant: The resultant vector, the sum of A and B, is drawn from the tail of Vector A (the origin) to the head of Vector B. This line represents the vector sum, Vector A + Vector B.
4. Measure and Determine Direction: Measure the length of this resultant line using your scale to find its magnitude. Use a protractor to measure its direction relative to a reference axis (like the positive x-axis).

Method 2: The Component Method (Mathematical Approach)

1. Resolve Each Vector into Components: Break down each vector into its horizontal (x-component) and vertical (y-component) parts. This is done using trigonometry:
   • For Vector A: A_x = |A| * cos(θ_A), A_y = |A| * sin(θ_A)
   • For Vector B: B_x = |B| * cos(θ_B), B_y = |B| * sin(θ_B)
   • (Where |A| and |B| are the magnitudes, and θ_A and θ_B are the angles measured from the positive x-axis).
2. Add Corresponding Components: Combine the x-components and y-components separately:
   • R_x = A_x + B_x
   • R_y = A_y + B_y
   • (R_x and R_y are the components of the resultant vector).
3. Calculate the Magnitude of the Resultant: Use the Pythagorean theorem:
   • |R| = √(R_x² + R_y²)
4. Determine the Direction of the Resultant: Use the inverse tangent function:
   • θ_R = arctan(R_y / R_x)
   • (Ensure the correct quadrant is considered when interpreting the angle).

Scientific Explanation The graphical method, based on the parallelogram law, provides a visual and intuitive understanding. It demonstrates that the resultant vector represents the diagonal of the parallelogram formed by placing the vectors tail-to-head. This method is excellent for conceptual understanding and quick estimates.

The component method is the preferred technique for precise calculations, especially when vectors are given in terms of their components or angles relative to a coordinate system. By decomposing each vector into orthogonal components (perpendicular to each other), the addition becomes a simple arithmetic operation on the independent x and y directions. The resultant's magnitude and direction are then derived from these summed components using basic trigonometry and the Pythagorean theorem. This method is the backbone of vector algebra in physics and engineering.

Example: Adding Two Vectors Let's apply these methods to a concrete example. Suppose we have:

• Vector A: 3 units in the direction of 37° north of east.
• Vector B: 5 units in the direction of 30° north of east.

Graphical Method (Parallelogram Law):

1. Draw Vector A: 3 units long at 37° NE.
2. Draw Vector B: 5 units long starting at the head of A, also at 30° NE.
3. Draw the resultant from the origin to the head of B.
4. Measure: The resultant length is approximately 7.1 units, and its direction is approximately 32° NE.

Component Method:

1. Resolve A:
   • A_x = 3 * cos(37°) ≈ 3 * 0.798 = 2.394 units (East)
   • A_y = 3 * sin(37°) ≈ 3 * 0.598 = 1.794 units (North)
2. Resolve B:
   • B_x = 5 * cos(30°) ≈ 5 * 0.866 = 4.330 units (East)
   • B_y = 5 * sin(30°) ≈ 5 * 0.500 = 2.500 units (North)
3. Add Components:
   • R_x = A_x + B_x = 2.394 + 4.330 = 6.724 units (East)
   • R_y = A_y + B_y = 1.794 + 2.500 = 4.294 units (North)
4. Magnitude |R| = √(6.724² + 4.294²) ≈ √(45.21 + 18.45) ≈ √63.66 ≈ 7.98 units.
5. Direction θ_R = arctan(4.294 / 6.724) ≈ arctan(0.639) ≈ 32.5° north of east.

Beyond the two‑vector case, the same principles extend naturally to any number of vectors. When adding three or more vectors, the component method remains the most straightforward: each vector is resolved into its orthogonal components, all x‑components are summed, all y‑components are summed (and, in three dimensions, the z‑components as well), and the resultant’s magnitude and direction are obtained from the resultant component set. This additive property holds because vector addition is both commutative and associative, meaning the order in which vectors are combined does not affect the final result.

In three‑dimensional problems, the procedure is identical apart from an extra axis. For a vector V with magnitude V and direction given by azimuth angle φ (measured from the positive x‑axis in the xy‑plane) and elevation angle θ (measured from the xy‑plane toward the positive z‑axis), the components are:

• Vₓ = V cos θ cos φ * V_y = V cos θ sin φ
• V_z = V sin θ

Summing the respective components of all vectors yields R = (Rₓ, R_y, R_z). The magnitude follows |R| = √(Rₓ² + R_y² + R_z²), and the direction can be described by two angles: the azimuth φ_R = atan2(R_y, Rₓ) and the elevation θ_R = atan2(R_z, √(Rₓ² + R_y²)). Many physics and engineering textbooks provide tables or software routines that perform these conversions automatically, reducing the chance of arithmetic error.

The graphical (parallelogram or polygon) method, while less precise for exact numbers, retains pedagogical value. It helps learners visualize how vectors combine, reinforces the concept of resultant as a single equivalent displacement, and offers a quick sanity check for computational results. In practice, engineers often sketch a rough polygon to anticipate the general direction and magnitude before refining the answer analytically.

Vector subtraction follows directly from addition by treating the subtrahend as a vector multiplied by –1 (i.e., reversing its direction). Thus, A − B = A + (−B), and the same component or graphical techniques apply.

Applications

• Kinematics: Determining net displacement or velocity from multiple segment motions.
• Forces: Computing the net force on a body when several forces act simultaneously—a cornerstone of statics and dynamics.
• Electromagnetism: Adding electric or magnetic field vectors from multiple sources.
• Computer Graphics: Combining translation, rotation, and scaling vectors to manipulate objects in 2‑D and 3‑D space.

Limitations and Considerations
The component method assumes an orthogonal coordinate system; if vectors are given in a non‑orthogonal basis, a transformation to an orthogonal frame is required first. Additionally, careful attention must be paid to sign conventions, especially when vectors point opposite to the chosen positive axes. In graphical constructions, drafting accuracy and scale selection directly influence the precision of the measured resultant.

Conclusion
Vector addition, whether approached graphically or analytically, is a fundamental tool that translates multiple directional quantities into a single, meaningful resultant. The component method excels in precision and scalability, making it indispensable for rigorous calculations in physics, engineering, and related fields. Meanwhile, the graphical method offers intuitive insight and a valuable verification step. Mastery of both techniques equips students and professionals to tackle a wide range of problems—from simple two‑vector scenarios to complex multi‑force, multi‑dimensional systems—with confidence and clarity.
